Mimaki TX330 Series

Price:
$39,250.00 USD
FINANCE NOW
When product is not in stock, usually the time to process is 5-7 days.

Description

Powering versatile, sustainable, high-quality textile production

The Tx330 Series offers expansive textile printing capabilities from a single platform, offering both pigment and dye sublimation. This remarkable printer series can print on the broadest selection of fabrics and textiles, with exceptional quality, while using minimal wastewater. In contrast to conventional textile printing processes that require pre- and post-processing equipment, the Tx330 Series streamlines production into a more space-efficient solution—ideal for users with limited space but still requiring a wide selection of applications.



TX330-1800

Hybrid textile inkjet printer with the ability to print on both fabric and paper. Options for two ink sets and the ability to easily switch the printing mechanism to accommodate direct fabric or transfer paper printing enables the production of soft-signage and short run interior fabrics.

  • Prints both dye sublimation and direct pigment inksets loaded separately or simultaneously on the same printer
  • The universal ‘do-it-all’ textile printer: dye and pigment from one platform. The Swiss army knife of printers
  • Can be equally configured for only dye-sublimation or only pigment direct printing as preferred



TX330-1800B

Similar to the Tx330-1800, but with the addition of a space-saving belt conveyor system to stably print on stretchy, thick, and thin fabrics commonly used for apparel. It supports short-run, variable apparel production in limited spaces, such as design offices, schools, and fabric retail stores.

  • Proven 330 printheads provide extraordinary quality and proven reliability
  • Utilizes a water-free process for direct printing pigment printing to fabrics, saving both time and money
  • A belt version of the printer is available for printing directly to elastic fabrics.



Our Core Technologies


img  Nozzle Check Unit
img Nozzle Recovery System
img Mimaki Bulk Ink System
img Uninterrupted Ink Supply System
img Mimaki Fine Diffusion
img Mimaki Circulation Technology
img Waveform Control
img Variable Dot Technology
img Mimaki Advanced Pass System



Specifications

Printhead

On-demand 330 Series piezo head (2 staggered layout)
Print Resolutions

300, 600, 900, 1200, 1800 dpi
Print Speed (4 color mode)

646 sq/ft per hr (60 sq/m per hr)
Maximum Print Width

Fabric:  75.2″ (1,910mm)
Paper:  76.4″ (1,940 mm)
Maximum Media Thickness

0.2″ or less (5.0mm)
Maximum Media Weight

88.2 lb or less (40kg)
Ink Type

Textile Pigment Ink TP410 (2L)
C/M/Y/K/R/Gr/Bl/Lk

Sublimation Dye Ink Sb420 (2L)
Bl/M/Y/K/Lb/Lm

At Hybrid Ink Set TP410 (2L)
C/M/Y/K
Interface

Ethernet 1000BASE-T (Recommended), USB2.0 Hi-Speed
Power Supply

AC100~120V/200~240V±10% 3A 50/60Hz±1Hz
Power Consumption

Max. 300W or less / Minimum 4.5W or less
Operational Environment

Temperature 68° – 86° F (20-30° C)
Humidity: 35–65 % RH (Non condensing)
Dimensions (W x D x H)

127.2″ x 38.0″ x 73.1″ (3,230 mm x 965 mm x 1,857 mm)
Weight (uncrated)

641.5 lb (291kg)
Certifications

TP410 is bluesign® APPROVED and Sb420/Sb411 are ECO PASSPORT certified
