Description
Big impact, Small Footprint
- Compact medium format design enables businesses to expand their production capabilities without requiring the space of a traditional wide-format printer.
- High versatility inks for printing to various rigid and flexible surfaces.
- Capable of producing 2.5D textures and ADA signage.
- Produce medium production volumes, such as printing multiple 18”x 24” signs simultaneously, or jig printing.
- IoT ready, Remote monitoring available through Mimaki PICT software for performance and production monitoring and event notification.
- Uses Greenguard Gold certified inks.
Our Core Technologies
Applications
Specifications
| Printhead |
Three staggered on-demand piezo heads |
| Print resolution |
300, 450, 600, 900, 1,200dpi |
| Print Speed (4 Color Mode) |
up to 269 SqFt/Hr (25 m2/h) |
| Maximum Print Area |
50.0 in x 51.2 in (1270 mm x 1300 mm) |
| Maximum media area |
52 in x 54 in (1320 mm x 1370 mm) |
| Maximum Media Thickness |
up to 1.97″ (50 mm) |
| Maximum Media Weight |
110.3 lbs. (50.0 kg) |
| Ink Type |
Rigid: LH-100 ink; C, M, Y, K, Lc, Lm, W, Cl Flexible: LUS-150 ink; C, M, Y, K, Lc, Lm, W with LUS-100 Cl LUS-120 ink; C, M, Y, K, W, Cl LUS-350 ink; C, M, Y, K, W, Cl |
| Interface |
Ethernet 10,000 BASE-T |
| Power Supply |
Single phase AC200-240±10% 50/60 Hz±1 Hz x 1 |
| Power Consumption |
2.88 kVA or less |
| Operational Environment |
Temperature 68° – 86° F (15-30° C) |
| Dimensions (W × D × H) |
125 in W x 96 in D x 49 in H (3175 mm W x 2450 mm D x 1250 mm H) |
| Weight |
1124 lbs. (510 kg) |
| Certifications |
VCCI Class A, CE Mark, CB Report, US safety standard UL (UL62368-1),RoHS Directive, FCC Class A, Machinery Directive, RCM |
Inks
| JFX200-1213 EX | Cyan | Magenta | Yellow | Black | Light Cyan | Light Magenta | White | Clear | Primer |
|---|---|---|---|---|---|---|---|---|---|
| UV Curable Ink (LH-100) 1L Bottle | LH100-C-BA | LH100-M-BA | LH100-Y-BA | LH100-K-BA | LH100-W-BA | LH100-CL-BA | |||
| UV Curable Ink (LUS-120) 1L Bottle | LUS12-C-BA | LUS12-M-BA | LUS12-Y-BA | LUS12-K-BA | LUS12-W-BA | LUS12-CL-BA | |||
| UV Curable Ink (LUS-150) 1L Bottle | LUS15-C-BA | LUS15-M-BA | LUS15-Y-BA | LUS15-K-BA | LUS15-LC-BA | LUS15-LM-BA | LUS15-W-BA | (Use LH-100) | |
| UV Curable Ink (LUS-350) 1L Bottle | LUS35-C-BA | LUS35-M-BA | LUS35-Y-BA | LUS35-K-BA | LUS35-W-BA | LUS35-CL-BA | |||
| UV Primer (PR-200) 1L Bottle | PR-200-Z-BA |
