About this product
A new standard in UV-LED flatbed printing. The JFX220-2515 is the newest addition to the Mimaki JFX family, a wide-format flatbed that brings advanced production features into a more accessible class. Positioned between the JFX200 EX Series and the JFX600 Series, it offers an expanded 98 in x 59 in bed (a full 4 ft x 8 ft board plus room for pre-cut pieces), Mimaki texture workflows for Braille and 2.5D effects, a new full-color control panel, pop-up registration pins, an enhanced self-masking vacuum system and new eco-friendly inks including fluorescent pink and yellow.
Four staggered on-demand piezo heads in a dual-CMYK configuration deliver up to 2x the production of the previous class at 226 sq ft/hr in 4-color mode, with a 4 in (101.6 mm) media clearance that opens dimensional and specialty applications. For wayfinding and directional signage, print providers get vivid, durable output with specialty textures and finishes on plastics, woods, metals and more.
- Up to 2x faster production - dual CMYK configuration and a larger print area
- New UV-LED fluorescent pink and yellow inks - high-visibility color for retail and event graphics
- Print on objects up to 4 in thick - expanded media height for dimensional work
- Faster media setup - Mimaki Anchor Technology self-masking vacuum control and pop-up edge registration pins
- Stronger vacuum without masking - 25 mm pitch suction holes, self-masking zones
- Advanced texture printing - 2.5D Texture Maker, Emboss and Braille
- New full-color control panel; RasterLink7 workflow
Applications
Specifications
| SKU | JFX220-2515 |
| Brand | Mimaki |
| Type | Printer |
| Condition | New |
| Printhead | Four on-demand piezo heads in a staggered array |
| Print Resolution | Y: 300, 600, 1,200 dpi | X: 300, 450, 600, 900, 1,200 dpi |
| Print Speed (4 Color Mode) | 226 sq ft/hr (21 sq m/hr) |
| Maximum Print Area (W x D) | 98.4 in x 59.1 in (2,500 mm x 1,500 mm) |
| Maximum Media Size | 98.4 in x 76.0 in (2,500 mm x 1,930 mm) |
| Maximum Media Thickness | Up to 4 in (101.6 mm) |
| Maximum Media Weight | 10.2 lb/sq ft or less (50 kg/sq m or less) |
| Vacuum Area | 25 mm pitch suction holes; self-masking vacuum control; pop-up registration pins |
| Ink Type | UV curable rigid ELH-100 (C, M, Y, K, Lc, Lm, W, Cl) | Flexible ELS-120 (C, M, Y, K, Lc, Lm, W, Cl) | Fluorescent EFS-150 (FP, FY) | IJ Primer PR-200 |
| Ink Capacity | 250 ml bottle (ELH-100, ELS-120, PR-200) | 1 L bottle (ELH-100, ELS-120, PR-200, EFS-150) |
| Interface | Ethernet 1000BASE-T |
| Power Supply | 2 lines: single-phase AC200-240 V ±10% 12A or less; single-phase AC200-240 V ±10% 10A or less |
| Power Consumption | INLET1: 2.88 kVA or less; INLET2: 2.33 kVA or less |
| Operational Environment | Temperature 59-86 °F (15-30 °C); best accuracy 68-77 °F (20-25 °C); humidity 35-65% (non-condensing) |
| Dimensions (W × D × H) | 173 in x 99 in x 59 in (4,400 mm x 2,250 mm x 1,490 mm) |
| Weight | 2,280 lbs (920 kg) |
| Options | OPT-J0216 Vacuum Unit (3-phase 200-240 V, 30 A, 3.4 kW); OPT-J0217 Vacuum Unit (single-phase 200-240 V, 30 A, 1.9 kW); OPT-J0232 Vacuum Unit (3-phase 380-480 V, 20 A, 3.4 kW); OPT-J0570 OP Blower Unit Connection Kit; OPT-01041 Patlite Signal Tower; OPT-01047 Ionizer unit x2; OPT-01048 Ionizer mounting bracket (for JFX220) |
| Certifications | VCCI Class A, FCC Class A, UL 62368-1-compliant ETL, CE Marking (EMC, Low Voltage, Machinery), IEC/EN 62368-1 (CB), RoHS, REACH, RCM, KC, UKCA |
