Aeoon Compact Micro Series

  • Sale
  • Regular price $125,000.00


For an industrial level performance at an entry cost

Compact Micro is the ideal addition to existing products with its compact size and makes entry into the DTG print industry easy.

Despite the small size of the machine, our customers achieve outstanding production volumes with top-quality printing results. Thanks to the newly developed software and integrated API interfaces, you can easily incorporate the Micro into existing and new print processes or online shop systems.

With Compact Micro, you can effortlessly realize small editions and individual jobs with a reasonable investment and manageable space occupation.

Output C6 – on a dark garment

Print size  (40 x 20 cm / ~16 x 8 in)*
Depending on the performance of the operator, on the material and design.

90Pieces per hour

Benefits:

  • Low capital expenditure enables entry into the world of digital textile printing
  • Easy integration into the automated production workflow
  • No use of pretreatment on white garments – for low print costs
  • Independent print stations with visualization for each print job
  • Industrial print heads with a print resolution from 600 dpi up to 2400 dpi
  • Integrated API interface
  • Big touch screen.

Angelo Schiestl, CEO & Founder of aeoon technologies

“A small but fast industrial printing press had been on my mind for a long time. The Mirco is space-saving, very attractively priced, meets all the new Industry 4.0 standards, and makes it easier to enter the professional world of customization!”

Technical specifications:


Industrial printheads: 6 or 8
Print stations: 2
Color channels: CMYK + 2W (6 Printheads)
CMYK + 4W (8 Printheads)
Max. Print size: 40 x 45 cm; 15,7 x 17,7 in
Printable material: Cotton, synthetics, mixed fibers, canvas, wood, leather, and more
Machine size: 200 x 170 x 150 cm; 78.7 x 66.9 x 59 in
Machine weight: 1000 kg; 2205 lb
Electrical connections: 400/208 VAC, 50/60 Hz, 3 Ph, 16 A – max. Power: 7.5 kVA
Compressed air: 7 bar – quality class 5
Environmental conditions:
depending on the ink used
Temperature: 22 – 28 °C,
Humidity: 65 – 90 %

PRODUCT BROCHURE, CLICK HERE
