The StarFire™ SG1024/SA is a compact, self-contained unit built to withstand demanding industrial textile and other applications. It uses field-proven materials to deliver consistent output over a long service life with continuous ink recirculation and single color operation at 400 dots-per-inch. Equipped with a single replaceable metal nozzle plate that is designed to withstand abrasion and resist damage. The unit is compatible with solvent, UV-curable, and aqueous ink formulations.
Each SG1024/SA printhead has 1024 independent channels arranged in 8 rows in a single nozzle plate for resolutions up to 400 dpi. All 1024 nozzles can be fired.
- Robust and repairable construction
- Drop size range: 12pl (50 Hz) - 33pl (18Hz)
- 1024 individually addressable jets
- Incorporate VersaDrop™ binary and grayscale jetting
- Continuous ink recirculation with RediJet™
- A removable/replaceable collar mounted, coated metal nozzle plate
COMPATIBLE PRINTER :
- Colaris NF 250
